UG-641

Name: UG-641
SKU: 11126
Price: 219389.34 ZAR
Availability: InStock

R219,389.34

*MSRP EXCL VAT*

(Manufacturer Suggested Retail Price)

Contact your local Authorised Roland Dealer as machine requires installation and training.

Categories: Large Format Printers, UV Print & Cut

Description

Your High-Value Choice.

Designed to Excite – High Volume, High Speed Production UV Print & Cut.

Combining the flexibility of print and cut, the benefits of UV-LED printing and Roland DG’s renowned commitment to reliability, the DGXPRESS UG Series makes professional UV print technology accessible to businesses of all sizes.

High-speed printing for maximum productivity.
Highly precise print expression.
Broad media compatibility.
Fast drying print for quick turnaround and finishing.
Specialty printing for textures and effects.
Versatile UV print and cut produces high-value applications on a wide variety of media.

Professional Features

Low Investment
Compact Footprint
Extension Table for Semi-rigid Card
One Touch Setup
Media Vacuum ensuring easy media set up
Resolution setting Max 1440 x1440 DPI
Perforated Cut

Enhance your capabilities with the added power of high-speed, reliable UV-LED printing technology, extensive media compatibility and specialty effects capabilities.

Applications

Short Term Signage
Product Packaging
Point of Sales
Backlit Displays
Labels and Decals
Vehicle Graphics
Window Displays
Decor

DOWNLOAD BROCHURE

Specifications

Printing method			Piezo ink-jet method
Media	Width		210 to 1625 mm (8.3 to 64 in.)
	Thickness		Max. 1.0 mm (39.3 mil) with liner, for printing Max. 0.4 mm (15.7 mil) with liner and 0.22 mm (8.6 mil) without liner, for cutting
	Roll outer diameter		Max. 210 mm (8.2 in.)
	Roll weight		Max. 40 kg (88 lb.)
	Core diameter		76.2 mm (3 in.) or 50.8 mm (2 in.)
Printing / cutting width¹			Max. 1600 mm (62.9 in.)
Ink	Type		UV-ink (D-UA) 220ml cartridge (white) UV-ink (D-UA) 500ml cartridge (cyan, magenta, yellow, black, and gloss)
	Colors		Six colors(cyan, magenta, yellow, black, white, gloss) Four colors(cyan, magenta, yellow, black)
Ink curing unit			Built-in UV-LED lamp
Print resolution (dots per inch)			Max. 1440 dpi
Cutting speed			10 to 300 mm/s (0.39 to 11.8 in./s)
Blade force²			30 to 500 gf
Blade	Type		Roland CAMM-1 series blade
	Offset		0 to 1.500 mm (0 to 59 mil)
Software resolution (when cutting)			0.025 mm/step (0.98 mil/step)
Connectivity			Ethernet (100BASE-TX/1000BASE-T, automatic switching)
Power-saving function			Automatic sleep feature
Power requirements			100-240 Va.c. 50/60Hz 2.8 A
Power consumption	During operation		Approx. 250 W
	Sleep mode		40 W
Acoustic noise level	During operation		63 dB (A) or less
	During standby		53 dB (A) or less
Dimensions (with stand)			2819 (W) x 781 (D) x 1316 (H) mm (111 [W] x 31 [D] x 52 [H] in.)
Weight (with stand)			163 kg (360 lb.)
Environment	During operation³	Temperature: 15 to 32 °C (59 to 89.6 °F), fumidity: 20 to 80 %RH (no condensation)
	Not operating	Temperature : 5 to 40 °C (41 to 104 °F), Humidity: 20 to 80 % RH (no condensation)

Specifications, designs and dimensions listed may be subject to change without notice

¹ The length of printing or cutting is subject to the limitations of the program.

² 500 gf is the maximum instantaneous blade force. The blade force must be adjusted according to details such as the media thickness.

³ Operating environment (Use in an operating environment within this range.)

Accessories

Inkjet Ink

Part No.	Description	Price
D-UA-5BK	DGEXPRESS UV Ink Black 500cc	R1352.00
D-UA-5MG	DGEXPRESS UV Ink Magenta 500cc	R1352.00
D-UA-5GL	DGEXPRESS UV Ink Gloss 500cc	R1352.00
D-UA-WH	DGEXPRESS UV Ink White 220cc	R811.20
D-UA-5YE	DGEXPRESS UV Ink Yellow 500cc	R1352.00
D-UA-5CY	DGEXPRESS UV Ink Cyan 500cc	R1352.00

Cutting

Part No.	Description	Price
CRT-2	Dual-Tip Creasing Tool	R788.48
XD-CH3	Blade Holder, Adjustable Tip, Regular	R921.43
XD-CH4-BL	Blade Holder, Adjustable Tip, Alloy, Blue	R921.43
XD-CH4-OR	Blade Holder, Adjustable Tip, Alloy, Orange	R1015.83
ZEC-U5032	45 Degree/.25 Offset Premium Blade – Standard Materials	R313.34
ZEC-U3050	60 Degree/.50 Offset Premium Blade. – Sandblast	R313.34
ZEC-U5032	45 Degree/.25 Offset Premium Blade – Standard Materials	R185.68
